ETCR2100C+ Clamp Ground Earth Resistance Tester 0.01-1200ohm 0.00mA-20.0A

Technical Specifications* Function: Ground resistance test, Loop resistance test* Clamp Size: Φ32mm* LCD Screen: 4 Digits LCD display, Screen L×W: 47mm×28.5mm* Resistance Range: 0.01-1200Ω;Current Range: 0.00mA-20.0A* Resistance Resolution:0.001Ω; Current Resolution 0.05mA* Highest Resistance Accuracy:±1%±0.01Ω; Current Accuracy ±2.5%±1mA* Data memory:99 Sets* Auto Power-off: 5 minutes after Boot up* Power Consumption: Max 50mA either in booting up or normally working, Continuously working for 30 hours* Working Temperature and Humidity: -20℃-55℃;20%RH-80%RH* Storage Temperature and Humidity: -20℃~60℃;90%RH* Alarm Threshold Setting Range:Resistance: 1-199Ω* Alarm Sound and Light: “Beep-beep-beep” alarm tone, Alarm Symbol Flashing, Press AL key to turn on, turn off Alarm or set Alarm Threshold. * Interference Signal Recognition:”Beep-beep-beep” tone, NOISE symbol blinking* Protection Level: Dual Insulation* Structural Feature: Clamp CT* Shifting: Automatic shifting* External magnetic field: <40A/m* External electrical field: <1V/m* Single measurement time: 0.5 second* Resistance measurement frequency: >1KHz* Measured current frequency: 50/60Hz Automatic measurement* Low Battery Indication: Low battery symbol displays when battery is lower then 5.3V* Memory Full Indication: MEM symbol blinks when all 99 sets memory is full* Over Range Indication: Out of range indication “OLΩ”, “L0.01” or “OL A”* Weight: 1120g* Clamp Dimension: L×W×T: 260mm×90mm×66mm* Power Supply: 4 PCS of AA alkaline batteries（Battery not included in the package）* Standard Accessories: Meter: 1; test loop: 1; meter box: 1* Optional Accessories: RS232 interfaceIf you need Optional Accessories,Please contact us.

• ETCR2100C+ Clamp Ground Resistance Meter measures ground faults that cannot be measured with conventional methods, can be used in applications where traditional methods cannot be measured, and is widely used for measuring ground resistance of various devices.
• Protection Level: Dual Insulation; Clamp Size: Φ32mm; Resistance Resolution: 0.001Ω; Current Resolution 0.05mA; LCD Screen: 4 Digits LCD display; Highest Resistance Accuracy:±1%±0.01Ω; Current Accuracy ±2.5%±1mA
• Alarm Threshold Setting Range: Resistance: 1-199Ω; Alarm Sound and Light: "Beep-beep-beep" alarm tone, Alarm Symbol Flashing, Press AL key to turn on, turn off Alarm or set Alarm Threshold.curacy:±1%±0.01Ω; Current Accuracy ±2.5%±1mA
• When measuring the looped grounding system, it is not necessary to disconnect the ground deflector and no auxiliary electrode is needed. Just clamp the meter and clamp it directly on the ground lead. The value displayed by the clamp meter is the grounding body resistance and The integrated value of the ground lead resistance, this measurement method can quickly and safely obtain the measurement results.
• Structural Feature: Clamp CT; ETCR2100C+ Ground Resistance and Loop Resistance Measurement (Range: 0.010Ω~1200Ω); Leakage Current Measurement (Range: 0.00mA~20.0A)
