Stainless Steel Panel Edge Trim – 20ga | #4 Brushed Finish - 48in
Product details
| Management number | 221681754 | Release Date | 2026/05/03 | List Price | US$27.98 | Model Number | 221681754 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
This 20ga Stainless Steel Edge Trim is a specialized finishing profile engineered to cap and protect the edge of sheet metal panels. Fabricated from Type 304 stainless steel with a #4 directional brushed finish, this trim delivers both functional durability and architectural appeal. The profile is specifically designed to accept 20 gauge panels (0.036" nominal) and features: A precisely formed 0.040" slot opening A rolled reveal flange (5/8") for aesthetic coverage A deep channel (1/2") to ensure secure panel capture A wide 1 1/8" mounting flange to facilitate mechanical or adhesive attachment This product is one of six trim types in the Epic QT stainless steel panel trim collection and is ideal for use in commercial kitchens, wall protection systems, enclosures, and stainless steel cladding projects. Technical Specifications Attribute Details Product Name Stainless Steel Panel Edge Trim – 20ga Manufacturer Epic QT (www.epicqt.com) Model ID PT180ET20-304SS48 Material 304 Stainless Steel Finish #4 Brushed (Directional Satin) Panel Compatibility 20 Gauge (0.036" / 0.91mm) Stainless Panels Trim Slot Opening 0.040" (1.02 mm) Channel Depth (Insert Depth) 0.50" (12.7 mm) Mounting Flange Width 1 1/8" (1.125" / 28.58 mm) Reveal Flange Width 5/8" (0.625" / 15.88 mm) Back Flange Height 3/8" (0.375" / 9.53 mm) Overall Thickness 1/4" (6.35 mm) Trim Length 48" Standard (Custom lengths available) Orientation Edge-mount Installation Options Adhesive, Screws, Rivets (not included) Use Environment Indoor or Outdoor, Wet or Dry Industry Use Cases Kitchens, Architectural Panels, Enclosures Installation Recommendations Apply with industrial-grade adhesive for flush wall-mounted panels. Use mechanical fasteners through the wide mounting flange for structural applications. Pair with matching corner trims and divider trims from the Epic QT Trim Series for a seamless full-panel system. Made in the USA!
- Accommodates 20ga Sheet Panels
- #4 Brushed Finish for clean, professional appearance
- Corrosion-Resistant Type 304 Stainless Steel
- Ideal for Edge Protection and Finishing Trim
- Thickness: 20ga = (.036") = 0.95mm
- Precision Rolled Reveal Flange (5/8") enhances aesthetics
- Length: 48 Inches
| Color | Silver |
|---|---|
| Material | Stainless Steel |
| Item Weight | 3 pounds |
| Part Number | PT180ET20-304SS48 |
| Manufacturer | Epic QT |
| Item model number | PT180ET20-304SS48 |
| Product Dimensions | 48 x 1.13 x 0.25 inches |
| Included Components | 1ea Edge Panel Trim |
| Item Package Quantity | 1 |
